Teadit Style 2138 Ramie Yarn - 1/8" CS x 2 lb. Spool - Paraffin Impregnated for Superior Sealing - Ideal for Industrial Gaskets, Packing & Valve Seals

SSS Style 2007 packing is an interlock braid, utilizing SSS’s unique proprietary PTFE/graphite yarn and a high temperature break-in lubricant This proprietary yarn is formed from expanded PTFE in which fine particles of pure graphite have been encapsulated The resulting packing combines the chemical resistance of PTFE with the heat dissipation characteristics of graphite, thus allowing much higher shaft speeds than conventional PTFE packings SSS Style 2007 is chemically inert over the entire 0-14 pH range with these exceptions: molten alkali metals, fluorides, aleum, fuming nitric acid, aqua regia, and other strong oxidizing agents This style is an excellent general service and corrosive service packing It is commonly used in pumps, valves, rotating and reciprocating shafts, mixers and agitators, and is especially designed for services involving surface speeds and temperatures higher than those that can be handled by pure PTFE packing

SSS Style 2138 packing is braided with high quality ramie yarns in a square plait construction

SSS Style 2138 is a well lubricated, medium-hard packing with extremely low frictional characteristics, which assure minimal shaft wear

The ramie yarn is rot and , making the packing ideal for marine use, handling cold water, salt water, and cold oils

6-8 pH range; Temperature maximum 212 F; Pressure Static to 20 bar (290 psi); Rotating to 15 bar (217 psi); Reciprocating to 15 bar (217 psi); Shaft Speed 1181 fpm (6 m/s)

87.8 ft. per pound. Approximate yields +/- 10%
